Headway simplex 48cores breakout optical fiber cab
Victoria Chen
Contact person
Basic Information
| Place of Origin | Zhejiang China (Mainland) |
|---|---|
| Brand Name | Headway |
| Model Number | GJFJV |
Headway breakout optical fiber cable ranges from 2-72cores, Design · Acrylate coated Fiber is tight buffered to 900mm with Nylon · Tight buffered fiber is surrounded by kevlar yarn. · The tight buffered fiber is then jacketed by fire resistance, low smoke and zero halogen PVC to 2mm in outer diameter. The jacket is yellow color · The number ID is printed on the cable. · 6/8/12/24 number of these cables are strained together around a central strength member and wrapped by a tape. · The cable is jacketed with fire resistance, low smoke and zero halogen PVC. The outer jacket is yellow color if fibers are single mode, Amber if fibers are 62.5mm multi mode or gray if fibers are 50mm multi mode. Mechanical Specification Crush Resistance 2000N/cm Impact Resistance 1500 times @ 1.6 N-m Minimum Installation Bending Radius 20 X Cable Diameter Minimum Resting Bending Radius 15 X Cable Diameter Maximum Installation Tension 2700N Maximum Resting Tension 700N Cable diameter 21.5MM Cable weight 360KGS/KM Cable length and drum size 1KM/DRUM with drum size of 110*70MM
Delivery terms and packaging
Packaging Detail: standard exported wooden drum with drum length of 500meters, 1000meters,2000meters, or as customers' requirments. Delivery Detail: 5days for shipment on receiving the down payment
Port: Shanghai
